摘要

LK Metrology 是坐标测量机 (CMM) 行业的领军企业,该公司寻求在其用于坐标测量机编程的 CAMIO 软件应用程序的代码和整体产品中开发出适应未来需要的强大功能。
当 LK Metrology 公司作为坐标测量机 (CMM) 行业的领军企业,希望在其 CAMIO 软件应用程序的代码和坐标测量机编程的整体服务中开发出面向未来的强大功能时,他们回到了
Spatial 业经验证的解决方案和程序。

LK Metrology 增加了 3D InterOp 和 HOOPS Visualize 以完善其 3D ACIS Modeler 的使用,并参与了评估计划。Spatial 评估计划使 LK Metrology 得以实施下一代 PMI/MBD 技术功能,从而延长了 CAMIO 的使用寿命,同时还受益于专家代码审查和对开发人员问题的解答。

Working closely together with Spatial, not only strengthened our knowledge of PMI and our CAMIO software but also provided very valuable feedback to Spatial which helped to improve the Uconnect product, thereby making our product better in the end.
Eric Hayes Director - Metrology Solutions
小六边形

公司

LK Metrology 于 1963 年在英国成立,是世界上历史最悠久的坐标测量机 (CMM) 制造商,也是 CAMIO 软件应用程序的创造者。

他们以创新的计量解决方案和服务闻名于世,其产品包括坐标测量机、激光扫描仪等新型传感器技术、表面光洁度等以及计量软件,在全球范围内广泛用于控制和提高制造部件的质量。他们的精密技术为汽车、航空航天、国防、赛车、能源、医疗和合同检验等全球行业从设计、开发、生产、组装到质量保证的整个流程链提供了支持。

LK Metrology 致力于使其产品保持尽可能高的精度,这也是他们引以为豪的客户利益。LK Metrology 的陶瓷技术坐标测量机具有令人印象深刻的体积精度,最小可达 2.1 微米,为业内其他公司树立了很高的标杆。LK Metrology 不仅可以完全按照客户的规格定制坐标测量机的尺寸,而且其软件应用程序 CAMIO 还可以实现精确的最终产品生产测量。CAMIO 具有针对各种坐标测量机应用的深入编程、分析和报告功能,可用于任何行业的测量。

LK Metrology 的客户生产的零件需要检测尺寸精度和工艺稳定性。这种对客户要求细节的关注为最终用户提供了无与伦比的产品,满足了他们的独特需求。事实上,CAMIO 的强大功能来自于 LK Metrology 为客户确定的特定关键功能,然后将其内置到客户的应用程序中。

DSC_2968
小六边形

挑战

追求三坐标测量机的精度

当计算机建模首次进入市场时,LK Metrology 决定将这项新技术集成到他们的计量硬件和应用中,从而彻底改变他们的产品和市场。经过二十多年的成功实施,LK Metrology 试图通过改进实践和工作流程来进一步改善他们的流程。他们的目标是升级到最好的 CAD 引擎和互操作性软件,同时充分利用实施方面的专业知识。

LK Metrology 团队勇于挑战自我,扩大应用范围,增强终端用户工作流程,重点关注精确的产品制造信息 (PMI) 和基于模型的定义 (MBD)。

他们的最终目标是扩展 CAMIO 的功能,使代码更加强大。

WLR Precision-3
尼桑工程图像 4b
WLR Precision-2

解决方案

通过开发合作伙伴关系改进核心应用程序功能

作为 Spatial 的长期客户,LK Metrology 已经在其 CAMIO 应用程序中嵌入了 Spatial 3D 组件,并熟悉这些组件提供的质量和功能。例如,在 20 世纪 90 年代,Spatial 的 3D ACIS Modeler 内核就被纳入了 CAMIO,从而可以使用本地 CAD 数据来开发和验证在线和离线 3D 检测程序。

除 ACIS 外,LK Metrology 还授权使用 HOOPS Visualize 和 3D InterOp 来增强 CAMIO 应用程序。3D InterOp 允许用户在不同的坐标测量机平台上导入、交互、共享和导出三维数据,而 HOOPS Visualize 则提高了 CAMIO 的性能和视觉显示效果。由于已经集成了这些高性能 Spatial 组件,LK Metrology 希望通过采用应用生命周期管理 (ALM) 框架,并通过 Spatial 的评估计划实施量身定制的三阶段方法,进一步提升其应用。

ALM 框架支持管理应用程序的生命周期,从开始、开发、维护到最终退出。应用程序开发人员可通过缩短发布周期、通过培训和研讨会扩大知识面,以及通过基于定制评估计划的强化产品管理,从 ALM 中获益。Spatial 的评估计划让 LK Metrology 确信,他们正在最大限度地发挥数据的潜力,同时提供工具和功能来改进最终用户的工作流程。

Spatial 专家团队与 LK Metrology 合作,共同确定挑战、讨论潜在的解决方案并发掘新功能。这种合作关系帮助 LK Metrology 扩展了功能,提升了应用水平。Spatial 清楚地了解 LK Metrology 作为一家国际多元化公司在地理方面的具体需求。

计量-图像-3
PMI
计量-图像-2

结果

高质量功能

通过集成 Spatial 的 3D InterOp,CAMIO 的互操作性使用户能够跨坐标测量机平台和制造现场导入、交互、共享和导出三维数据。3D ACIS建模器的几何验证功能可自动识别CAD模型的哪些表面应用于测量,应用适当的接触点或扫描路径策略,同时避免无效几何。编程工作流程中的高级选取功能可让用户从选项列表中选择正确的特征类型,而无需额外的交互。自动传感器选择、全探头路径模拟和间隙规避盒等附加功能进一步增强了 CAMIO 产品组合。

整合 PMI 和 MBD 以扩展能力

LK Metrology 公司知道,他们的产品制造信息(PMI)和基于模型的定义(MBD)的实施需要改进,并需要一些额外的帮助。因此,Spatial 帮助将 PMI 和 MBD 读取和处理技术集成到 CAMIO 中,这是扩展应用功能的重要部分。然后,Spatial 与 LK 公司协商,审查他们的实施情况,以确保其安全、高效和稳健。因此,用户现在可以快速识别图形 PMI 和语义 PMI 之间的联系。然后,他们就可以将特征、基准特征和公差添加到现有的教学路径工作流程中,从而对项目进行逻辑排序,并应用测量策略和清除动作。这一过程只需最少的用户输入,即可创建大段的 DMIS 代码。

主要观点

支持下一代坐标测量机软件

icon-bulb

展望未来的计量市场,里程碑是明确的:代码的精确性和准确性仍然至关重要,同时还需要自始至终为软件应用程序开发人员提供经过行业验证的流程支持。

随着基于模型的定义(MBD)和产品制造信息(PMI)日益受到重视,客户越来越有可能将这些功能作为软件的标准配置

LK Metrology 公司的精密解决方案已经超越了行业标准,他们希望通过开发代码的稳健性和扩展功能,使其 CAMIO 应用程序面向未来。他们相信 Spatial 能够提供全面的解决方案,并探索文件格式的新可能性,在整个过程中受益于 Spatial 的质量和功能改进。通过与 Spatial 这样的专家合作,LK Metrology 继续引领坐标测量机行业,树立了卓越的典范,展示了计量软件所能达到的效果。他们的客户非常看重 Spatial 久经考验的世界级组件的可靠性、强大功能和先进性能。
