Lubansoft 案例研究
市场:建筑信息管理(BIM)



摘要
鲁班软件公司是中国 BIM 技术的领军企业,需要为其软件提供功能强大且全面的 3D 建模内核。他们需要更多的功能和更少的运行故障。
通过实施 3D ACIS Modeler,Lubansoft 的应用程序可显著提高其稳定性和性能,同时受益于通过成千上万的使用案例获得的稳健性。Lubansoft 实施 3D ACIS Modeler 和 HOOPS Visualize 后,简化了产品开发、缩短了上市时间、提高了产品竞争力、拓宽了产品线并提高了客户满意度。

Lubansoft is a specialized construction BIM software and service provider. Through our decade-long cooperation with Spatial, Lubansoft can take advantage of the world's leading 3D modeling kernel and graphics platform and, thereby, be able to devote our research and development energies to the creation of higher value-added specialized applications. Using Spatial's SDKs has raised the competitiveness of our products, accelerated the pace of software development and shortened our time to market.
公司
Lubansoft 的企业级建筑信息管理 (BIM) 系统(Luban PDS)是一个工程基础数据平台,创新性地将尖端 BIM 技术应用于建筑行业项目管理的整个过程。Lubansoft 的 BIM 应用客户端可移动使用,能够支持建筑行业的移动办公要求。
鲁班软件成立于 2001 年,专注于中国 BIM 技术的研发和推广。公司专注于施工阶段的 BIM 技术项目,以及企业级解决方案的研发和
服务。
除提供鲁班 PDS 外,公司还开发了许多专业客户端应用程序,用于创建三维 BIM 模型、计算工作量、可视化等。Lubansoft 的模型和计算应用程序,如
鲁班建筑"、"鲁班钢铁 "等模型和计算应用程序,以及公司的大部分计算系列产品都基于 AutoCAD。然而,由于 AutoCAD 在三维建模和可视化方面的局限性,该公司现在使用 Spatial 的 3D ACIS Modeler 进行三维 BIM 模型创建、布尔运算、体积计算和其他几何运算,并与 Spatial 的 HOOPS Visualize 集成以显示复杂模型。

挑战
寻求工业级 3D 建模和可视化
建模内核
早期,鲁班建筑设计公司使用的是 AutoCAD 内置的三维建模功能;但是,AutoCAD 的强项是二维绘图平台,而不是三维建模引擎。由于 AutoCAD 中的三维建模内核既不强大也没有完整的功能,这不仅影响了鲁班建筑设计公司的性能,还导致了许多布尔运算失败。功能的缺乏加上操作失败影响了计算的准确性和程序的稳定性。因此,迫切需要一个更稳定、功能更全面的三维建模内核来替代 AutoCAD 三维建模引擎,以提高软件的稳定性和计算的准确性。
可视化
Lubansoft 的旗舰产品建立在 AutoCAD 内核的基础上。除了有限的三维建模能力,AutoCAD 在三维可视化方面的能力也非常有限。例如,显示一个相对复杂的三维 BIM 模型(如一栋 20 层的建筑)会导致性能迟缓。缺乏有效显示复杂 3D BIM 模型的能力使 Lubansoft 在竞争中处于劣势。
随着客户需求的增加,Lubansoft 需要开发一个独立于任何第三方设计软件的平台,以管理 3D BIM 模型的数据和相关功能。该平台需要能够有效地显示复杂的 3D BIM 模型,并有效地执行包过滤、场景漫游、切割平面和动画等操作。



解决方案
建模内核
鉴于 AutoCAD 作为三维建模内核的缺点,Lubansoft 开发团队用 3D ACIS Modeler 取代了 AutoCAD 三维建模内核。30 多年来,3D ACIS Modeler 一直引领着三维建模内核市场,提供了满足 BIM 行业需求的强大建模功能。通过转向一个在全球拥有 200 多万个用户的、经过行业验证的解决方案,Lubansoft 的应用程序现在可以显著提高其稳定性和性能,同时受益于通过数以千计的使用案例而获得的稳健性。
BIM 行业需要稳定可靠的布尔运算。3D ACIS Modeler 中的布尔函数支持多种布尔运算符。对于最复杂的布尔运算,3D ACIS Modeler 具有强大的增量布尔运算功能。这种增量例程可以访问强大的模型检查和修复功能,因此可以有效地测试和修复由建模问题引起的错误,提高后续布尔运算的成功率和效率。
3D ACIS Modeler 对多线程的支持使 Lubansoft 应用程序能够快速执行创建不同图层或布尔运算等操作。通过集成 CGM 多面体建模器,Lubansoft 还可以通过集成的 API 接口同时处理多面体几何体和精确表示。
可视化
由于现有解决方案的可视化功能有限,Lubansoft 将 HOOPS Visualize 纳入 Luban PDS 系统平台和需要浏览 3D BIM 模型的相关 Lubansoft 应用程序中。
HOOPS Visualize 强大的大型模型可视化功能特别适合复杂 3D BIM 模型的可视化。HOOPS Visualize
还提供了各种高级可视化功能,如阴影、纹理、透明度、Gooch 渲染和其他基于色彩的图形效果 - 开发人员只需将这些功能添加到应用程序中即可提高其产品的价值。



结果
简化产品开发;缩短上市时间
通过授权使用 Spatial 的 3D ACIS Modeler 和 HOOPS Visualize 组件,Lubansoft 极大地简化了开发工作,减少了资源需求,并有效缩短了应用程序的交付时间。现在,Lubansoft能够在短短6个月内完成新应用程序的开发。
提高产品竞争力
标准化的 ACIS 建模内核提高了计算产品的稳定性和性能,并提高了计算的准确性。无论在 PC 还是移动平台上,Lubansoft 都能流畅灵活地处理大型场景的 3D BIM 模型,提高了客户对其产品的可及性。
拓宽产品线
原始建模引擎的局限性不仅限制了 Lubansoft 产品的性能,也限制了产品线的广度。以前,Lubansoft 的核心产品主要是土木工程计算器和钢筋计算产品。现在,该公司已开发出一个完整的 BIM 系统平台,其中包含十几个专业应用程序。Spatial工具包提供的新功能使 Lubansoft 能够开发出涵盖 100 多个应用点的产品,并延伸到建筑项目的每个阶段。
提高客户满意度
基于 3D ACIS Modeler、CGM Polyhedra 和 HOOPS Visualize 的新鲁班 BIM 系统现在可支持更广泛的客户应用,可在各种平台上使用,并提供更高的稳定性和性能。性能和功能的提升大大提高了 Lubansoft 的客户满意度。
主要观点
解决方案
通过将 Spatial 的三维软件工具包纳入其 BIM 软件套件,Lubansoft 能够提高设计质量、减少设计错误、获取并分析工作量成本数据,从而为施工、运营和维护的整个过程提供支持。三维 BIM 模型质量的提高确保了在保证质量水平的前提下,在客户预算范围内及时完成建设项目。此外,Spatial 工具包还使 Lubansoft 建立了一个平台,从办公室到施工现场,无论是台式机、平板电脑还是手机,都能实现协作。阅读更多Spatial案例研究
