摘要

Virtual Motion 是一家领先的 CAE 软件供应商,提供机械系统动力学建模和分析。作为一家私人投资的公司,Virtual Motion 需要快速向市场推出新产品以创造收入。然而,该公司缺乏时间和资源来开发自己的 3D 几何内核。

Virtual Motion 集成了 Spatial 3D ACIS Modeler,并利用 AGM 和 HOOPS 加速 DAFUL 软件开发。使用 AGM 和 ACIS 后,开发时间缩短了 50%,Virtual Motion 通过强大的 3D 建模 API 获得了竞争优势。

When I outsource software to be part of my product, the company’s reputation, reliability and support infrastructure are very important to me.
Prof. Daesung Bae Director of Research and Development
小六边形

公司

Virtual Motion 成立于 2006 年,开发并销售用于机械系统动力学和有限元分析的 CAE 软件解决方案 DAFUL(韩语,意为 "多物理场")。DAFUL 可对刚性和柔性体系统进行动态分析,每个系统都可能发生较大的平移和旋转位移(多体动力学)。

DAFUL 目前在韩国多个市场销售,包括汽车(如现代汽车及其子公司和零部件供应商)、电子(如 LG 和三星)和重工业(如卡特彼勒)。Virtual Motion 计划通过本地化版本和新的软件应用程序(包括计算流体动力学、控制和优化)将业务扩展到新的地区市场。

Virtual Motion 的客户使用 DAFUL 大大降低了与机械系统设计相关的成本和时间。零部件设计人员使用该软件对虚拟原型进行分析,以确保设计符合功能和安全要求。如果没有 DAFUL,设计人员需要构建多个成本高昂的原型,才能实现理想的设计。

2020-12-ansys-academic-ansys-student-product
小六边形

挑战

寻找合适的第三方 3D 建模内核

Virtual Motion 面临的最大挑战是利用有限的人力和财力开发软件。此外,公司还需要尽快将软件推向市场,以便开始创收。由于上市时间紧迫,公司决定为软件的 3D 建模内核寻求第三方解决方案。

Capture décran 2024-09-12 170302
虚拟运动2
虚拟运动3

解决方案

让 3D ACIS Modeler、AGM 和 HOOPS 尽展所长

Virtual Motion 研发总监 Daesung Bae 教授曾在前一家公司工作,拥有使用市售图形内核的经验,他考虑过 UGS Parasolid(现为西门子),但最终选择了 Spatial 的 ACIS 技术、应用图形管理器 (AGM) 和 HOOPS 应用框架。

选择 Spatial 组件的决定基于一系列重要因素:

  1. 图形性能和库的易开发性和可靠性--Virtual Motion 开发人员发现,ACIS 内核具有非常好的面向对象类库,因此非常易于编程,尤其是与其他选项相比。

  2. 灵活的定价模式 - Spatial 的定价模式与 Virtual Motion 的软件定价和打包模式相匹配。

  3. 与其他面向对象软件的兼容性和翻译器的易用性,两者都能最大限度地减少编程工作。

  4. Spatial 的 AGM 库加快了 HOOPS 和 ACIS 的应用程序开发(Parasolid 缺乏这一功能)。

此外,在裴教授权衡其他选择时,Spatial 区域经理的响应速度和专业精神给他留下了深刻印象。"当我外包软件作为我产品的一部分时,公司的声誉、可靠性和支持基础设施对我来说非常重要。

基础设施对我来说非常重要。

从一开始,Spatial 为 Virtual Motion 开发人员提供的实际操作方法就给 Bae 教授留下了深刻印象。Spatial 派技术专家到公司进行了为期一周的培训,在此期间,Bae 教授能够深入讨论 Virtual Motion 如何利用 ACIS、HOOPS

和 AGM 优化其软件。

我们首先创建了一个向几何内核发送信息的接口,用于更改图形属性。这样,Virtual Motion 开发人员就无需在多个地方重复相同的开发代码。因此,AGM 大大加快了开发时间,从而缩短了产品上市时间。

Virtual Motion 还选择了 Spatial 的 HOOPS 3D 应用程序框架及其内置的图形仿真流程,从而最大限度地减少了开发工作量。"我们的系统有一个图形用户界面,可以构建机械系统的组件并以三维方式显示。

Bae 教授说。"HOOPS有一个非常好的界面,可以将我们的组件与Spatial组件连接起来,以管理菜单布局等图形视图"。

Virtual Motion 的客户有时会在 DAFUL 中构建 3D 几何图形,但大约 80% 的客户会从其他 CAD 系统导入模型。Virtual Motion 计划使用 3D InterOp 转换器来促进数据导入,以便轻松集成 STEP 和 Parasolid 的高级 3D 数据互操作功能。

CHAIN_DRIVE_BEHAVIOR_640x300
d4d69d84-2017-03-22-thumb-4t-figuras-wb
Capture décran 2024-09-12 170623

结果

大幅缩短开发时间
通过使用 Spatial,Virtual Motion 公司的整体开发时间缩短了 50%。"Spatial 使我们能够最大限度地减少编程工作,因此我们能够加快自己的软件开发速度,从而在公司成立后不久就能创收,"裴教授评论道。"此外,图形质量和性能也非常好。
Bae 教授对 Spatial 的技术和服务非常满意,并向其他公司强烈推荐 Spatial,因为 Spatial 的可靠性以及 Spatial 组件与 DAFUL 组件集成的便捷性。

Capture décran 2024-09-12 170602

主要观点

Spatial 的 SDK 行业领先是有原因的。
第 111 组

解决方案

Spatial 的 SDK 被世界各地的公司用来加速其软件开发。Virtual Motion 意识到 3D ACIS Modeler 和补充解决方案的强大功能,并因此获得了关键的竞争优势。

下载完整案例研究

想要了解更多有关 Virtual Motion 如何从使用 ACIS Modeler 中获益的详细信息吗?请点击以下链接下载完整的案例研究。

阅读更多Spatial案例研究

了解我们业界领先的 SDK 如何帮助多个垂直领域的无数企业。浏览
我们的其他案例研究。
