功能全面
通过一整套几何对象以及广泛的尺寸和逻辑约束，可以定义和修改二维轮廓以及三维装配的相对定位。
CDS
二维和三维模型几何约束求解器
约束设计求解器（CDS）是一个几何约束求解器 SDK，可实现最佳零件和装配设计。利用 CDS 重新计算草图和组件在装配中的位置，确保所有设计元素都符合指定的约束条件。
促进优化零件和装配设计性能
利用约束设计求解器（CDS）释放零件和装配设计的全部潜能。这款先进的 SDK 可以重新计算二维和三维模型中的草图和部件位置，确保所有设计元素都符合指定的约束条件。CDS 支持多种约束条件，并提供高性能求解器来处理最复杂的几何关系，非常适合需要精确的真实世界模拟行为的应用。利用 CDS 提高生产率、缩短上市时间并增强设计精度。
约束设计求解器的主要功能
.svg)
几何对象
CDS 为约束系统提供多种几何图形，支持二维和三维表示。其中包括点、线、非均匀有理 B-样条曲线和曲面、圆、椭圆、抛物线、双曲线、圆柱、圆锥、球面和环面。
.svg)
几何限制
通过各种尺寸约束，包括坐标、距离、长度、半径、角度和曲率，指定具体数值。利用重合、相切、平行、垂直和对称等逻辑约束建立几何对象之间的关系。
-1.svg)
高级限制
CDS 可在应用中实现高级约束，包括用户定义的表达式和条件、刚性集、模式、关节和手性的局部控制。实现任意数量的几何自由度，利用平面、外旋、棱柱、圆柱、球面、万向和全 DOF 关节促进逆运动学。
.svg)
实时互动
CDS 使应用程序能够通过快速求解器对几何对象进行实时操作，并支持对约束条件进行交互式模型修改。如果系统无法求解，CDS 会提供有关冲突约束的全面诊断信息。
.svg)
质量保证工具
重放和脚本功能以及图形显示环境确保了调试的简便性和快速实施。利用 CDS 的质量保证工具强调准确性。
.svg)
求解器模式和选项
CDS 的核心是一个非线性同步方程求解器，它提供三种不同类型的求解模式：自动定位几何体以满足所有约束条件的更新模式；沿自由度子空间移动一组几何体的交互式拖动模式；以及允许几何体在满足约束条件的同时达到定义目标值的模拟模式。
