计量软件开发人员的高级解决方案

您是否正在寻求一种几何内核,为您的计量应用提供更高的性能水平?您是否需要高级功能来处理几何数据?Spatial 的软件开发工具包(SDK)可帮助您在计量应用中发挥最佳性能。

background-glow
您的挑战

软件开发的主要挑战
计量软件开发

Group (78)
精确测量
减少误差,确保精确的尺寸和几何精度。

Group (66)
简化版
软件
为复杂的计量工作流程创建用户友好型界面。

Group (54)-1

CAD 系统
适应 CAD 更新并在流程中保留设计意图。

Group (74)
自动化
计划

通过自动、一致的测量计划简化工作流程。

AdobeStock_59767802
AdobeStock_91574295
AdobeStock_83674862

我们的 SDK 如何解决
您的计量挑战

从 CAD 模型导入 PMI

使用 Spatial 的 3D InterOp,您的团队可以构建计量软件,通过从 3D CAD 模型导入 PMI(产品制造信息),生成测量计划并保留设计意图。我们的客户在利用 PMI 创建检测计划时可节省多达 90% 的时间。

成熟的应用程序开发框架

Spatial 的 AGM(应用图形管理器)是一个完整的 3D 应用开发框架。它提供了一系列多功能工具,用于制作弹性三维应用程序。这个包罗万象的框架跨越多个功能层,包含用户界面框架、错综复杂的几何图形撤消/重做、渲染引擎等元素,同时确保与所有其他 Spatial SDK 的无缝集成。

几何约束求解器

约束设计求解器(CDS)是一个几何约束求解器 SDK,有助于优化零件和装配设计。CDS 模拟解决坐标测量机的逆运动学问题,并根据几何约束条件在坐标测量机设备上定位物体。

工作原理

提升您的计量水平
软件工作流程

准备好提升您的计量工作流程了吗?我们的三维建模、互操作性和可视化解决方案可根据您的需求定制工作流程。
https://10956.fs1.hubspotusercontent-na1.net/hubfs/10956/Additive-Manufacturing-spatial-feature%20(15)-2.webp

1.CAD 数据导入

  • 快速可视化导入
  • 选择性 B-Rep 导入
  • 语义和图形 PMI
  • CAD 关联性

https://10956.fs1.hubspotusercontent-na1.net/hubfs/10956/2.png

2.部件分析

  • PMI 分析
  • 特征检测

https://10956.fs1.hubspotusercontent-na1.net/hubfs/10956/3.png

3.准备工作

  • 测量规划
  • 特征选择
  • 尺寸
  • 几何取样

https://10956.fs1.hubspotusercontent-na1.net/hubfs/10956/4.png

4.加工

  • 逆运动学
  • 碰撞检测

https://10956.fs1.hubspotusercontent-na1.net/hubfs/10956/6.jpg

5.后期处理

  • 距离计算
  • 结果可视化
  • 报告生成

升级您的应用程序

专为计量工作流程打造的功能

Spatial 的解决方案具有特定的内置功能,可满足计量行业的独特需求。
计量行业的独特需求。选择的功能包括
处理几何数据、支持大型点云和支持
处理撤消/重做的回滚机制。

捕捉设计意图
部分分析
生成测量点
注释分析
优化传感器路径
通过战略路径规划加强运行安全
碰撞检测
利用先进的点云处理技术优化数据整合
1

捕捉设计意图

在 CAD 环境中直接无缝访问和利用原始 CAD 注释,确保精确的尺寸和几何关系。该功能可直接验证工程公差和规格,提高测量和分析的准确性。它支持全面了解几何公差、公差类型、公差值及其相关的特定面或边,从而促进全面高效的验证过程。

2-1 3

部分分析

利用直观的几何特征检测系统,自动进行测量规划并生成有深度的报告。通过分析面的组合,这种先进的算法可以识别并分类孔、垫、袋、圆角和倒角等特征。它明确定义了要测量的几何形状,包括面的细节和轴线方向,从而简化了测量过程。此外,它还提供参数定义来预测测量结果,包括直径、深度和孔类型(盲孔或通孔)等方面,从而简化分析,提高准确性和效率。

4-1

生成测量点

通过使用平面和非平面切片以及投影和偏移操作,从零件的几何形状中精确生成测量点,从而在模型上准确标记点。在标称零件上有效创建和优化传感器路径。在零件上,可根据这些曲线对检测测量点进行详细比较,从而提高精度并确保质量控制。

6-1 5

注释分析


利用基准面和 DATUM 信息,为测量提供精确的工件定位。通过使用
复合 PMI,实现测量活动的自动分组。特征检测与复合 PMI 之间的这种整合,可对共享注释的特征进行高效测量。

7-1 8-1

优化传感器路径

利用模型几何图形,通过查询几何对象自动优化传感器路径的创建,评估器会计算特定位置的法线和曲率。这一过程可将传感器路径生成为沿面或沿边的点序列,确保全面覆盖。这可确保沿着面和边的全面覆盖。

9

通过战略路径规划加强运行安全

通过在工件和机器周围创建 "禁区",降低测量和检测过程中的冲突风险。这可以通过偏移主体并按预定距离扩大其体积来实现,以确保安全的操作缓冲区。此外,在路径生成过程中,通过偏移面来补偿测头半径,从而准确确定测头的中心位置。这种周密的计划不仅可以保护设备和要检测的工件,还可以保持测量过程的完整性,确保获得精确可靠的结果。

10

碰撞检测

采用先进的碰撞检测算法,可预先识别测头、夹具、工件和机器之间的潜在碰撞,确保设备和被测物的完整性。利用适合实时应用的快速并行处理技术,在不影响安全的情况下保持操作流程。通过离线路径规划,提前验证测量计划,避免刨削工件的风险。强大的逆运动学算法还能模拟终端执行器(探头)沿被测物体的位置。

12 11

利用先进的点云处理技术优化数据整合

利用惯性矩阵和最小二乘法拟合相结合的两阶段对齐过程,将测量数据与三维模型精确对齐。该方法计算每个点与几何图形的距离,并标明其与内部或外部状态的位置关系。计算实际测量点与标称零件几何图形之间的距离,并指出每个测量点与内部或外部状态的位置关系。将测量结果与公差进行比较,评估制造精度
并识别 "过切 "或 "欠切 "等偏差。利用高性能并行化架构,有效处理大型数据集,确保进行快速、可扩展的比较,从而实现有效的分析和质量控制。

AdobeStock_207810607
AdobeStock_5820921
AdobeStock_343139532

为什么使用Spatial SDK 进行开发?

与 Spatial 的合作意味着可以使用成熟的建模技术、领先的
翻译器、强大的网格划分组件、与渲染器的紧密集成以及省时的应用程序开发框架。
省时的应用程序开发框架。
第 193 组

关注你的附加值

与自行开发 CAD 导入解决方案相比,使用 3D InterOp,坐标测量机/计量应用软件的开发人员就可以摆脱支持 CAD 版本定期更新的负担。
第(28)组-1

更快进入市场

通过开发自己的软件解决方案,可以确保软件支持与硬件能力同步。在经过验证的组件基础上进行开发,可以提高开发人员的工作效率。
组 (27)

改善用户体验

用户体验必须流畅,软件必须与机器的工作方式紧密结合。我们为您提供所需的工具,帮助您构建一个涵盖整个用户工作流程的应用程序。
组 (24)

无与伦比的 3D 专业技术

35 年来,Spatial 一直是三维建模组件领域的领导者,我们提供独有的达索系统成熟技术。

开始使用Spatial技术

我们是否拥有将您的三维应用工作流程提升到新水平的技术?请与 Spatial 专家联系。
