雷尼绍案例研究

雷尼绍是世界领先的工程和科学技术公司,为各行各业提供工业自动化和过程控制解决方案与服务。


市场:自动化制造

产品
3D ACIS Modeler CGM Polyhedra 3D InterOp
_0001_renishaw-logo-removebg-preview
_0007_renishaw
background-glow

摘要

雷尼绍是世界领先的工程和科学技术公司,提供工业自动化和过程控制解决方案与服务。雷尼绍希望摆脱以 STL 为中心的文件导入流程及其局限性,同时最大限度地减少工程工作量。

雷尼绍迁移到 Spatial 的 3D ACIS Modeler 后,获得了世界一流的愈合、高级建模和编辑能力的飞跃。Spatial 的高质量 SDK 使雷尼绍能够为未来的 CAD 功能铺平道路。

Our collaboration with Spatial now allows us to not only perform high-quality healing on STL files but, more importantly, to import various CAD formats directly.
Stephen Anderson Director of Group Software
小六边形

公司

雷尼绍是工程技术领域公认的世界领导者,在产品开发和制造方面有着悠久的创新历史。如今,这一创新历史已延伸至设计、开发和生产先进的金属快速成型制造系统,用于直接制造三维打印金属部件。

在三维打印之前,有必要生成打印机的激光扫描路径,使粉末层相互融合,从而以增材制造的方式形成部件。因此,构建准备软件是生成高质量部件构建的关键。为了最大限度地提高自有打印机的构建质量,并为工业客户提供一个简单的用户界面来定位、支持和设置构建参数,雷尼绍开发了自己的构建准备工具 - QuantAM。

QuantAM专为雷尼绍AM平台设计,与机器控制软件紧密集成,能够在生产前准确、快速地检查所有构建文件。

Enrico-Orsi-di-Renishaw-con-pezzo-e-macchina-3000x2000-1
小六边形

挑战

摒弃以 STL 为中心的文件导入方式

数字驱动的快速成型制造系统需要一个文件准备阶段,将原始 CAD 几何图形格式化为机器可读的构建文件。最常见的 CAD 导出格式是立体光刻 (STL)。STL 格式将曲面描述为连接三角形的集合,曲面越复杂,定义曲面所需的三角形数量就越多。

虽然 STL 导入在行业中发挥了很好的作用,但这种格式也有一些局限性:

  • 例如,用三角形集合描述的球体只能接近球体参数化模型的精度(永远无法达到描述的简洁性)。
  • 如果在输出时选择了错误的三角形密度,就会影响最终的打印质量。最终用户必须充分了解设备的打印分辨率。
  • 由于 STL 表示法是一种近似值,它限制了编辑模型的能力并使之复杂化。
  • 在翻译模型意图时出现错误,任何修复都是手动的,不够完美。
  • 固定/修复后的模型与原始模型存在差异,使保持规格同步变得更加复杂。
  • 不支持产品和制造信息(PMI)。
六角模板-renishaw2
六角模板-renishaw1
六角模板-renishaw3

解决方案

强大的本地建模内核

雷尼绍的软件工程团队为QuantAM 2017设计了一个全新的平台,对其当前平台进行了重大调整。
在 Spatial 技术团队的帮助下,雷尼绍在 QuantAM 中集成了两个关键组件
QuantAM 中集成了两个关键组件:带有 CGM 多面体的 3D ACIS Modeler 和 3D InterOp。

转向 ACIS 建模内核

QuantAM解决方案的一个重大变化是转向ACIS建模内核,不再仅仅依赖模型的STL表示。改用本地建模内核为雷尼绍及其客户带来了显著优势。

世界级的愈合能力

3D ACIS Modeler提供了一组强大的功能和例程,可以处理拼接、几何简化和间隙紧缩等棘手的建模问题。3D ACIS Modeler附加组件CGM多面体为QuantAM提供了在网格数据上使用强大的多边形愈合功能--这是一项重要的功能,因为STL导入的数据往往不完美,掩盖了模型的意图。

高级建模

通过使用 CGM 多面体和 3D ACIS Modeler,QuantAM 现在可以从精确的 B-rep 和多面体混合建模功能中获益。例如,CGM 多面体可以识别 STL 模型中的平面、圆柱体、圆锥体、环体和球体等可视曲面,将这些结构转换为精确的表示,从而保留原始模型的意图。

编辑能力的飞跃

由于导入的数据现在是真正的三维混合模型,因此可以对混合模型进行几何修改、编辑和修正。更新后的模型可以反馈给原始设计团队,使他们能够审查为使零件可制造而做出的任何修改。3D ACIS Modeler 实现的这一新流程实现了基于模型的工程设计,其中模型就是规范,允许将制造中的任何更改反馈给整个系统。

集成 3D InterOp

借助3D InterOp,QuantAM现在可以导入许多新的建模格式,使雷尼绍能够支持更多的客户和工作流程,包括所有主要的CAD供应商和相关格式。通过增加对其他 CAD 系统原生格式的支持,QuantAM 可以导入原始设计意图,不仅可以导入几何数据,还可以导入产品结构和装配、图形表示和 PMI。

b9940f9945e4408699d110e0de0add5a
65950433c4334bcaa216da4d8d6d7792
a2c9791f22798520312830fc8b04d97c

结果

能力互补

从业务角度看,与 Spatial 的合作为雷尼绍提供了一套互补的能力,凸显了这种长期、富有成效的合作关系的优势。从工程设计的角度来看,雷尼绍获得了经过数百家客户数千个数据集测试的强大解决方案。Spatial工程团队在处理三维建模以及翻译来自不同供应商的CAD数据库方面拥有多年的经验,同时还能保留设计意图,这使团队受益匪浅。

因此,在向客户推出新代码时,团队无需处理常见问题。此外,由于解决方案集的成熟性和稳健性,支持问题的数量也大大减少。雷尼绍的客户可以从 Spatial 社区所需的任何代码修复和改进中获益。

0918-am-renishaw-quantam

主要观点

Spatial 的 SDK 行业领先是有原因的。
第 111 组

解决方案

因此,在向客户推出新代码时,团队无需处理常见问题。此外,由于解决方案集的成熟性和稳健性,支持问题的数量也大大减少。雷尼绍的客户可以从 Spatial 社区所需的任何代码修复和改进中获益。

下载完整案例研究

想了解雷尼绍如何将Spatial SDK集成到其应用程序中的详细情况?点击下面的链接下载完整的案例研究。
