IMSI/Design, LLC社 事例

カリフォルニアに本社を置くIMSI/Design, LLCは、リテールCADのグローバルリーダーである。同社の製品には、受賞歴のある精密・グラフィック設計アプリケーションのTurboCAD®、TurboFLOORPLANTM、RenditionerTM、DesignCADTMファミリーがある。


インダストリー
木工、建築、宝飾品製造などの精密設計用途

製品
3D ACIS Modeler 3D InterOp
イムシロゴ
0011_IMSI
background-glow

概要

IMSI/Design, LLCはリテールCADのグローバルリーダーです。IMSIは3Dジオメトリカーネルを入手し、TurboCADへの統合を検討していましたが、同社の製品開発計画に対応するために容易に拡張できるものではありませんでした。そこで、TurboCADをより早く市場に投入できるようにするため、3D ACIS Modelerを採用しました。

同社がSpatial社を選んだ理由は、3Dソリッドモデリングエンジンにおける価格/性能のリーダーであり、相互運用性というIMSI/Designの中核的な強みと、市場における価格/性能のリーダーになるという独自の戦略に完璧に合致していたからです。Spatialの業界で実証された技術により、IMSIのTurboCADは、スピード、精度、機能対価格の価値という前例のない組み合わせを提供することができます。

ACIS and its extensions help our software developers bring new features to market more rapidly. Through our long-term relationship we’ve gained development effi ciencies and are better able to respond to our customer’s requests for new functionality in existing and future products.
Bob Mayer COO
小さなヘクス

会社概要

MSI/Designは、急速に成長するメタバース(3D仮想現実世界)のサポートや、CADワークフローへのGoogle SketchUp 3Dモデルの統合など、新しく革新的なCAD分野の最前線にいます。

TurboCADは汎用性が高いため、幅広い3Dモデリング、製図、ビジュアライゼーション用途に最適です。同ソフトウェアの機能が大幅に強化されたことで、同社のインストールベースは主にコンシューマー向けから、よりプロフェッショナルな構成へとシフトしている。

コンシューマー向けから、よりプロフェッショナルな構成へとシフトしている。木工職人、建築家、宝飾品メーカーなどに世界的に人気のあるこのソフトウェアは、日本語、簡体字中国語、繁体字中国語、フランス語、ドイツ語、スペイン語、チェコ語に完全にローカライズされています。

03-手頃な価格のCADデザイン・ソフトウェア
小さなヘクス

課題

成長するモデリングカーネルを求めて

IMSIは、買収によって3Dジオメトリカーネルを入手し、TurboCADへの統合を検討しましたが、同社の製品開発計画に対応するための拡張が容易ではありませんでした。さらに、モデリング エンジンの開発と保守にかかるコストは、サードパーティのソリューションをライセンス供与するコスト/利益を上回るものでした。

キャプチャ・デクラン 2024-09-12 155251
キャプチャデクラン 2024-09-12 154439
キャプチャ・デクラン 2024-09-12 154448

解決策

Spatial社のACIS Geometry Kernelと3D InterOp Suiteの統合

IMSIは約10年前、Spatial社のACISモデリング・カーネルのライセンスを取得することで、TurboCADをより早く市場に投入できると判断しました。「IMSI/Design社の最高執行責任者(COO)であるボブ・メイヤー氏は、次のように述べています。「当社の開発アプローチは常に、精密設計ソフトウェアの開発というコアコンピテンシーに集中し、自社で開発するためのリソースを費やすのではなく、クラス最高のコンポーネント技術をサードパーティに求めるというものでした。

同社がSpatial社を選んだ理由は、3Dソリッドモデリングエンジンにおける価格と性能のリーダーであり、相互運用性というIMSI/Designの中核的な強みと、市場における価格と性能のリーダーになるという独自の戦略に完璧に合致していたからです。

IMSIの開発者は1年以内にACISをTurboCADに統合しました。今日、ACISを搭載したTurboCADは、押し出し、ロフト、穴、エンボス、曲げなどの複雑な編集や変形を可能にします。2008年初頭、IMSIとSpatialは、TurboCADのWindowsおよびMacベースの製品ライン全体でSpatialの3Dコンポーネント技術を統合する長期契約を締結しました。

3D InterOpトランスレーター。

長年にわたり、両社の開発者は密接に協力し、特にデフォーマブル・モデリングに関して、IMSIの顧客向けにSpatialコンポーネントを最適化してきました。3D変形モデリングは、3Dモデルを成形するためのインタラクティブなスカルプトツールで、高品質で製造可能なサーフェスを維持し、自由形状のBスプライン曲線やサーフェスの簡単な作成と操作を可能にします。この機能により、TurboCADユーザーは、豊富な制約セットに自動的に準拠する形状をインタラクティブに形成することができ、「そうでなければ制御点操作で達成することが極めて困難、あるいは不可能であった」曲線やサーフェスの操作を実行できるようになる、とMayer氏は指摘する。

これらの異なる市場すべてに対応するIMSIの開発計画にとって、Spatialが提供するどのような機能が重要だったのでしょうか。「拡張性です」とメイヤーは言う。「私たちは、ACISから始めて成長できるものを求めていました。メイヤー氏は、IMSIはまだSpatialの機能をすべて使いこなせていないと指摘する。「メイヤーは、IMSIはまだSpatialの機能をすべて使いこなしていないと指摘する。

キャプチャデクラン 2024-09-12 154519
キャプチャデクラン 2024-09-12 154404
移動加入者識別番号

結果

競争優位性の向上

「TurboCAD は Spatial 社と長い付き合いをしており、ACIS の性能と品質が年々向上するのを見てきました。「3D変形モデリングツールの継続的な進化により、Spatialの一連のサブシステム・ソリューションは、私たち企業にとっても、エンドユーザーにとっても、素晴らしい投資であったと言えます。

メイヤーは、両社の長期にわたる関係が成功したのは、技術面でもビジネス面でもオープンなコミュニケーションがあったからだとしている。「メイヤー氏は、「Spatial社は、官僚主義に染まっておらず、市場におけるリーダー的地位を維持するために迅速に行動することを好む私たちのような中小企業にとっては、本当にありがたい存在です。「技術的な問題であれ、ビジネス的な問題であれ、私たちの質問やニーズに応えてくれ、連絡をくれることに感謝しています。

Capture décran 2024-09-12 154503

重要な洞察

スペイシャルのSDKが業界をリードしているのには理由があります
グループ111

解決策

IMSIの開発スタッフは、ACISの新バージョンを迅速に統合することができたため、同社は12~15カ月ごとにTurboCADの新バージョンを市場に投入することができた。

事例の全文をダウンロード

IMSI社がどのようにスペイシャルのSDKをアプリケーションに統合したのか、事例の全文をダウンロードして詳細をご確認ください。
